Stratasys F170 3D Printer

The Stratasys F170 3D Printer  lets you print everything from fast, low-cost concept models to durable assemblies and offers users the choice of low cost PLA, ABS-M30 and ASA materials.

Stratasys F170 open material bay

The Stratasys F170 3D Printer  lets you print everything from fast, low-cost concept models to durable assemblies and offers users the choice of low cost PLA, ABS-M30 and ASA materials.

Materials are fed from two material bays along with Stratasys easy-to-remove soluble support material . The F170 features 2 material spool bays, 1 for model, 1 for support located in an easy to access drawer at the front of the unit

It’s easy to create complex parts and assemblies with no compromise on accuracy, detail and repeatability. Even for your earliest design iterations, you can expect Stratasys quality and dependability.


F170 - Maximum Build Size (XYZ) 254 x 254 x 254 mm (10 x 10 x 10 in.)


A variety of the most commonly used CAD file formats can be imported directly into the software. The three printers in the platform, the Stratasys F170, F270 and Stratasys F370, support a broad range of capabilities and budgets for every stage of prototyping.


Minimal setup means you can simply plug and play to give your entire office access to professional 3D printing. Auto-calibration ensures you spend less time troubleshooting and more time prototyping.


Fast and easy material swaps to help maximize your design team’s productivity.
The Stratasys F123 series features an all-new fast-draft mode to produce initial design concepts quickly and economically. Now you can print twice as fast as standard build mode whilst reducing cost by on average consuming just a third of the material. Offering a wider choice of materials further efficiency and savings can be gained by using PLA. A thermoplastic made from renewable resources, PLA - gives you the speed of fast-draft mode while keeping material expenses down. Spend less, create more - That’s smarter 3D printing

Exceptional Value


The all-in-one power of the Stratasys F123 series gives you value all around — with expanded capabilities and unprecedented accessibility. New and improved features save time and material. Incredible ease of use with both the hardware and the software means you don’t need special 3D printing expertise. Super quiet and office friendly.  Reliable, consistent printing ensures less waste.

More Images

Related Pages

Enquire now

Key Features

Build Size
(XYZ) 254 x 254 x 254 mm (10 x 10 x 10 in.)
Material Choices
PLA, ABS-M30 & ASA plus QSR support material
Ease of Use
Office friendly Simply plug and play, powered by GrabCAD software
Perfect for

• Design Engineers
• Product Designers
• Animators
• Internal Rapid Prototyping Departments
• Small run end use parts
• Education Research Institutes/Universities

Contact us with your questions on this product »

Product information

Material Delivery Options  - 2 material spool bays, 1 for model, 1 for support located in a drawer on the front of the unit, Network Connectivity Wired: TCP/IP protocols at 100 Mbps minimum 100 base T, Ethernet protocol, RJ45 connector
Wireless: IEEE 802.11n, g, or b; Authentication: WPA2-PSK, 802.1x EAP; Encryption: CCMP, TKIP Software GrabCAD Print (download):

Requirements

Size and Weight 1626 x 864 x 711 mm (64 x 34 x 28 in.) 227 kg (500 lbs) with consumables Noise Specification 46 dB maximum during build, 35 dB when idle
